Over Braided InterLocked Metal Liquid Tight Conduit ( SM-701 )

Heavy series flexible sheath fittings
Heavy Series Fittings

High Strength InterLocked Over Braided Liquid Tight Conduit is most suitable for industry machines wirings demanding high mechanical strength with high abrasion and hot metal swarfs resistance.
*Galvanized steel helically wound (interlocked) with PVC coating and wire over-braid.
*Trade size: 3/8"~6" (
Interlocked profile for increased tensile strength.*Liquid-tight
*EMI shielding *Explosion proof (for use in Hazardous Location) *High Tensile strength

Delikon, experts in the manufacture of heavy series over braided flexible conduit and fittings for industry automation power and data cables protection. Our flexible conduit systems offer reliable cable protection solutions for PLC, sensors, machining centers, industry robots and other demanding industrial applications.

Delikon, experts in the manufacture of heavy series over braided flexible conduit and fittings for industry automation power and data cables protection. Our flexible conduit systems offer reliable cable protection solutions for PLC, sensors, machining centers, industry robots and other demanding industrial applications.

Over Braided InterLocked Metal Liquid Tight Conduit for machine cables protection

Heavy Series Over Braided Flexible Conduit For Glass Industry Equipment Wiring

  • MADE FROM INTERLOCKED LIQUID TIGHT CONDUIT WITH WIRE OVER-BRAID:
    *Wire over-braiding provides more abrasion resistant, EMI shielding and resistance to hot metal splashes.
    *
    Explosion proof.
    Liquid-tight.
    *Durable and long life.
    *High tensile strength.
    *Inner core made from  galvanized steel strip.
    *Interlocked construction prevents unraveling
  • Applications:
    This Flexible Metal Conduit is suitable for use in Hazardous Locations; Industrial environments where higher abrasion resistance or screening are required.
    Braided flexible conduit for CNC machine wiring assembly
  • Related Products:
    Liquid tight flexible Metal conduit without wire over-braid. Suitable for machines.
    Model YF-706  Model YF-806
    Liquid tight metal conduit with nylon cord packing InterLocked Liquid tight Flexible Metal Conduit





Electrical flexible conduits for offshore oil and gas industry cable protection
Offshore & Heavy industrial wiring flexible conduit

Heavy Series Over Braided Flexible Conduit for high temperature industry applications
Heavy Series Over Braided Flexible Conduit for high temperature industry applications
Over Braided Flexible Metal Conduit offers excellent protection to cables against hot metal splash in steel mills. For steel mill retrofit.

Stainless Steel Over Braided Liquidtight ConduitOver braided liquid tight conduit with nylon sealing cord

EMI/RFI Shielding conduit: This conduit is designed to protect sensitive electronic circuits in applications such as communications, radar and data transmission from Electro-Magnetic and Radio Frequency Interference (EMI / RFI). This braided liquid tight flexible metal conduit is most suitable for radar equipments, airports, CNC machineries and PLC wirings in industrial environments. Industry Control Flexible Conduit

Type Trade Size I.D. (mm) O.D. (mm) Min Bending Radius (mm) Meter/Coil
MIN. MAX. MIN. MAX.
SM-70103 3/8" 12.3

12.8

18.5 19.0 75 50
SM-70104 1/2" 15.7 16.3 21.8 22.3 95 50
SM-70106 3/4" 20.7 21.2 26.2 27.7 120 30
SM-70110 1"

26.2

26.8 33.8 34.4 180 30
SM-70112 1-1/4" 34.7 35.4 42.4 43.2 230 20
SM-70114 1-1/2" 40.0 40.6 48.4 49.3 270 20
SM-70120 2" 51.3 51.9 60.4 61.3 300 15
SM-70124 2-1/2" 62.9 63.6  73.1 74.0 350 10
SM-70130 3" 77.9 78.7 88.9 89.9 500 10
SM-70140 4"  101.6 102.6 114.3 115.3 650 5
SM-70150 5" 126.0 128.0 133.0 135.0 800 5
SM-70160 6" 149.0 151.0 156.0 158.0 1000 5
Stainless steel braid provides extra protection. This interlocked over braided liquid tight conduit is highly resistant to wear, abrasion and electric sparks or hot metal splashes. This conduit is also resistant to common oils and grease in industry environments and has good flexibility and good mechanical resistance. Interlocked over braided liquid tight conduit also offers good protection against electromagnetic interference across a large wave band.
