LOW SMOKE,HALOGEN FREE Water-tight Flexible Metal Conduit (LSHF)

Extensively used in mass transit systems electric wirings

Flexible metallic conduit with low smoke, halogen free, water tight jacket:
*This water proof flexible steel conduit is designed for applications where safety concerns exist regarding a material's reaction in a fire situation.
*Water tight jacket made of low smoke, halogen free thermal- plastics, with excellent flame retardation and low smoke and toxicity generation characteristics.
*Durable and long life.
*Inner core made from galvanized steel strip.
*Square locked construction for more flexibility or interlocked for more strength.
.
Applications:
This product is ideally suited for installation in confined or enclosed areas where construction materials must have limited smoke, low flame spread and low toxic gas emissions in the event of fire. Such applications include mass transit vehicles where water proof flexible conduit is extensively used for wiring harnesses within and under passenger rail cars. Other applications include use in underground subway structures and tunnels.
.
Related Products:
With normal PVC covering for general applications.
>>> Model YF-707

All metallic for EMI shielding and hot metal splashes resistance.
>>> Model SM70001

Overbraided Flexible steel conduit with steel braid

Machine Grey liquid-tight flexible steel conduit is used extensively in the machine tools.

With metal wire braids for EMI Shielding and abrasion resistant.

Small ID Metal Hose >>>

The specially formulated thermoplastic jacket has excellent flame retardation and low smoke and toxicity generation characteristics. Acidic gases such as hydrogen chloride, hydrogen fluoride and hydrogen bromide are virtually eliminated as products of combustion.

*Halogen Free *Low Fire Hazard *Self Extinguishing

SQUARE-LOCKED
Type	Trade Size	I.D. (mm)		O.D. (mm)		Min. Bending Radius (mm)	Meter/Coil
Type	Trade Size	Min.	Max.	Min.	Max.	Min. Bending Radius (mm)	Meter/Coil
LSHF-70702-SQ	1/4"	9.7	10.2	14.4	14.7	45	100
LSHF-70703-SQ	3/8"	12.3	12.8	16.4	16.8	50	50
LSHF-70704-SQ	1/2"	15.8	16.2	20.3	20.7	65	50
LSHF-70706-SQ	3/4"	20.8	21.3	25.6	26.0	75	50
LSHF-70710-SQ	1"	26.4	27.1	32.6	33.1	100	50
LSHF-70712-SQ	1-1/4"	35.0	35.5	41.2	41.7	125	30
LSHF-70714-SQ	1-1/2"	40.1	40.6	47.2	47.8	150	25
LSHF-70720-SQ	2"	50.5	51.2	58.7	59.4	175	20
LSHF-70724-SQ	2-1/2"	62.9	63.9	74.1	75.1	200	10
LSHF-70730-SQ	3"	77.0	78.0	89.0	90.0	225	10
LSHF-70740-SQ	4"	99.6	101.6	111.2	112.4	275	10
INTERLOCKED (HIGH TENSILE STRENGTH)
Type	Trade Size	I.D. (mm)		O.D. (mm)		Min. Bending Radius (mm)	Meter/Coil
Type	Trade Size	Min.	Max.	Min.	Max.	Min. Bending Radius (mm)	Meter/Coil
LSHF-70702-IN	1/4"	9.70	10.2	14.2	14.5	45	100
LSHF-70703-IN	3/8"	12.3	12.8	16.3	16.6	50	50
LSHF-70704-IN	1/2"	15.8	16.2	20.3	20.7	65	50
LSHF-70706-IN	3/4"	20.8	21.3	25.5	26.0	75	50
LSHF-70710-IN	1"	26.4	27.1	32.4	32.9	100	50
LSHF-70712-IN	1-1/4"	35.0	35.5	40.8	41.3	125	30
LSHF-70714-IN	1-1/2"	40.1	40.6	46.7	47.2	150	25
LSHF-70720-IN	2"	50.5	51.2	58.3	59.0	175	20
LSHF-70724-IN	2-1/2"	62.9	63.9	73.1	74.1	200	10
LSHF-70730-IN	3"	77.0	78.0	88.2	89.2	225	10
LSHF-70740-IN	4"	99.6	101.6	110.2	112.0	275	10

*All sizes and dimensions listed above are subject to manufacturing tolerances. non halogen conduit
*Standard Packaging: Shrink wrapped coil. Other custom packaging methods or of longer length is also possible upon request and our approval. non halogen conduit non halogen conduit flexible steel conduit

LOW SMOKE, HALOGEN FREE Water-tight Flexible Metallic Conduit ( LSHF-707 ) non halogen conduit

Most suitable for rail way system or ship electrical wirings applications Galvanized steel strip core (square locked or interlocked) Specially formulated thermoplastics, *low smoke, halogen free* 1/4"~4" trade size Water-tight *Low Fire Hazard non halogen conduit	Non-Halogen, Low Smoke and Low Flame Spread are what makes Type LSHF a proven choice for field installation in confined, public areas such as subways, tunnels, etc.
